The diesel engine (also known as a compression-ignition or CI engine), named after Rudolf Diesel, is an internal combustion engine in which ignition of the fuel, which is injected into the combustion chamber, is caused by the elevated temperature of the air in the cylinder due to the mechanical compression (adiabatic compression). Diesel engines work by compressing only the air. This increases the air temperature inside the cylinder to such a high degree that atomised diesel fuel injected into the combustion chamber ignites spontaneously. This contrasts with spark-ignition engines such as a petrol engine (gasoline engine) or gas engine (using a gaseous fuel as opposed to petrol), which use a spark plug to ignite an air-fuel mixture. In diesel engines, glow plugs (combustion chamber pre-warmers) may be used to aid starting in cold weather, or when the engine uses a lower compression-ratio, or both. The original diesel engine operates on the "constant pressure" cycle of gradual combustion and produces no audible knock.
In 1892, Diesel received patents in Germany, Switzerland, the United Kingdom and the United States for "Method of and Apparatus for Converting Heat into Work". In 1893, he described a "slow-combustion engine" that compressed air, thereby raising its temperature above the ignition point of the fuel, then gradually introducing fuel while letting the mixture expand "against resistance sufficiently to prevent an essential increase of temperature and pressure", then cutting off fuel and "expanding without transfer of heat". In 1894 and 1895, he filed patents and addenda in various countries for his engine; the first patents were issued in Spain (No. 16,654), France (No. 243,531) and Belgium (No. 113,139) in December 1894, and in Germany (No. 86,633) in 1895 and the United States (No. 608,845) in 1898.
Diesel's original engine injected fuel with the assistance of compressed air, which atomized the fuel and forced it into the engine through a nozzle (a similar principle to an aerosol spray). The nozzle opening was closed by a pin valve lifted by the camshaft to initiate the fuel injection before top dead centre (TDC). This is called an air-blast injection. Driving the compressor used some power but the efficiency was better than the efficiency of any other combustion engine at that time. Also, air-blast injection made engines very clunky and heavy and did not allow for quick load alteration, thus redering it unusable for road vehicles.
Diesel engines are also produced with two significantly different injection locations: "direct" and "indirect." Indirect injection engines place the injector in a pre-combustion chamber in the head, which, due to thermal losses, generally require a "glow plug" to start and a very high compression ratio, usually between 21:1 and 23:1. Direct injection engines use a generally donut-shaped combustion chamber void on the top of the piston. Thermal efficiency losses are significantly lower in DI engines which facilitates a much lower compression ratio, generally between 14:1 and 20:1 but most DI engines are closer to 17:1. The direct injection (DI) process is significantly more internally violent and thus requires careful design and more robust construction. The lower compression ratio also creates challenges for emissions due to partial burn. Turbocharging is particularly suited to DI engines since the low compression ratio facilitates meaningful forced induction. The increase in airflow allows capturing additional fuel efficiency, not only from more complete combustion, but also from lowering parasitic efficiency losses when properly operated, by widening both power and efficiency curves. The violent combustion process of direct injection also creates more noise, but modern designs using "split shot" injectors or similar multishot processes have dramatically ameliorated this issue by firing a small charge of fuel before the main delivery, which pre-charges the combustion chamber for a less abrupt, and in most cases slightly cleaner, burn.
