An automatic transmission, also called auto, self-shifting transmission, n-speed automatic (where n is its number of forward gear ratios), or AT, is a type of motor vehicle transmission that can automatically change gear ratios as the vehicle moves, freeing the driver from having to shift gears manually. Like other transmission systems on vehicles, it allows an internal combustion engine, best suited to run at a relatively high rotational speed, to provide a range of speed and torque outputs necessary for vehicular travel. The number of forward gear ratios is often expressed for manual transmissions as well (e.g., 6-speed manual).
Besides the traditional hydraulic automatic transmissions, there are also other types of automated transmissions, such as a continuously variable transmission (CVT) and semi-automatic transmissions, that free the driver from having to shift gears manually, by using the transmission's computer to change gear, if for example the driver were redlining the engine. Despite superficial similarity to other transmissions, traditional automatic transmissions differ significantly in internal operation and driver's feel from semi-automatics and CVTs. In contrast to conventional automatic transmissions, a CVT uses a belt or other torque transmission scheme to allow an "infinite" number of gear ratios instead of a fixed number of gear ratios. A semi-automatic retains a clutch like a manual transmission, but controls the clutch through electrohydraulic means. The ability to shift gears manually, often via paddle shifters, can also be found on certain automated transmissions (manumatics such as Tiptronic), semi-automatics (BMW SMG, VW Group DSG), and CVTs (such as Lineartronic).
The automatic transmission was invented in 1921 by Alfred Horner Munro of Regina, Saskatchewan, Canada, and patented under Canadian patent CA 235757 in 1923. (Munro obtained UK patent GB215669 215,669 for his invention in 1924 and US patent 1,613,525 on 4 January 1927). Being a steam engineer, Munro designed his device to use compressed air rather than hydraulic fluid, and so it lacked power and never found commercial application. The first automatic transmission using hydraulic fluid may have been developed in 1932 by two Brazilian engineers, Josй Braz Araripe and Fernando Lehly Lemos; subsequently the prototype and plans were sold to General Motors who introduced it in the 1940 Oldsmobile as the "Hydra-Matic" transmission. They were incorporated into GM-built tanks during World War II and, after the war, GM marketed them as being "battle-tested."[citation needed] However, a Wall Street Journal article credits ZF Friedrichshafen with the invention, occurring shortly after World War I. ZF's origins were in manufacturing gears for airship engines beginning in 1915; the company was founded by Ferdinand von Zeppelin.
A better known car that also used planetary transmission was Henry Ford's Model T of 1908. The Model T, in addition to being cheap and reliable by the standards of the day, featured a simple, two speed plus reverse planetary transmission using straight cut gears whose operation was manually controlled by the driver using pedals. The pedals actuated the transmission's friction elements (bands and clutches) to select the desired gear. In some respects, this type of transmission was less demanding of the driver's skills than the contemporary, unsynchronized manual transmission, but still required that the driver know when to make a shift, as well as how to get the car off to a smooth start.
The first torque converter automatic, Buick's Dynaflow, was introduced for the 1948 model year. It was followed by Packard's Ultramatic in mid-1949 and Chevrolet's Powerglide for the 1950 model year. Each of these transmissions had only two forward speeds, relying on the converter for additional torque multiplication. In the early 1950s, BorgWarner developed a series of three-speed torque converter automatics for American Motors, Ford Motor Company, Studebaker, and several other manufacturers in the US and other countries. Chrysler was late in developing its own true automatic, introducing the two-speed torque converter PowerFlite in 1953, and the three-speed TorqueFlite in 1956. The latter was the first to utilize the Simpson compound planetary gearset.
